The first in Europe

The first product of its kind
on the European market

Home

Quick installation

Easily manage the quick and simple
installation process

Home

For every terrain

autoLIBERT will pull you out from mud, sand, and snow

autoLIBERT_SUV1
autoLIBERT_SUV1
autoLIBERT_SUV1
now takes a smarter approach
autoLIBERT_SUV1

Home
Autodoplnok určený
na vyprostenie pri zapadnutí

Obsah balenia

2 x hliníkový blok
2 x hliníkové nadstavce
2 x popruhy s račňou
1 x návod na použitie

Home
Home

Výrobok je na sklade

90,00 €

SKU: 000001 Category:

Additional information

Weight4,5 kg
Dimensions36 × 11 × 15 cm

autoLIBERT

For every off-road and SUV

Compact car accessories with which you can afford to get stuck


Video clips

Home

autoLIBERT off-road

Home

Off-road installation

Home

Instructions for use

3-step installation

With autoLIBERT, you’re only three steps from setting yourself free

Home

1 – Start with the installation

Check the distance between the tire and the fender. Put the aluminum block on the tire so that that the free end of the strap runs into the fender and pull it through the disk toward yourself.

2 – One step closer to extrication

Put the strap with the disc protection pad on the side of the tire or on the disc so that it does not exceed the clear height of the tire and does not cover the valve.

Home
Home

3 – Keep on conquering the terrain

Check whether the ratchet can be fully opened after the pad was placed on the wheel. Put the free end of the strap into the ratchet and pull it. Close the ratchet mechanism and fasten it firmly.


Home

Safe assembly

Always assemble autoLIBERT with the engine off, on the drive axle, and on both sides

Home

Permitted clearance height

The minimum distance of the tire from the edge
of the fender must be 5 cm.

Home

Always outside the valve

During installation, the strap must not cover the valve.


autoLIBERT

Technical parameters

Home

Vehicle type: offroad, SUV
Minimum clearance height: 5 cm

Aluminium block

Material:Extruded anodized aluminium
Weight:0,48kg
Maximum load:6t
Height:28mm
Width:90mm
Length:150mm

Aluminium extension

Material:Extruded anodized aluminium
Weight:0,95kg
Maximum load:6t
Height:23mm
Width:90mm
Length:300mm

Strap

Material:Polyester fabric
Width:25mm
Length:1,5m
Thickness:2mm
Maximum load:MBS: 2250kg, LC 2000 daN
Ratchet:oceľ LC 800 daN
